Order Hillrom™ HeartCentrix® Reports

NextGen® Enterprise EHR Help

View Hillrom™ HeartCentrix® Exercise ECG Reports

After ordering a Cardiac Science Exercise ECG report, you can view it. Open the Integrated Equipment Module From the IEM grid, select a Cardiac Science Exercise ECG Report record with a Test Status of Confirmed, UnconfirmedOnly, or Reconfirmed. Select View Report. The HeartCentrix® Exercise ECG report opens. Note: If the patient has multiple race entries, then for Cardiac Science multiple race entries, the race is interpreted as Other. If the system finds a suitable match from information supplied in the Patient Information window, it populates the Race field. Otherwise, the field defaults to "Unknown." Select the HeartCentrix Main toolbar items as needed (functions are dependent on user permissions and view mode). After making any changes, select Confirm to save changes and return to the IEM. For more information on how to use HeartCentrix® functionalities, refer to the appropriate HeartCentrix® user manual. Parent topic: Hillrom HeartCentrix Devices

NextGen® Enterprise EHR Help

View Hillrom™ HeartCentrix® Resting ECG Reports

After ordering a Cardiac Science Resting ECG report, you can view it. In NextGen® Enterprise EHR, load a patient and select a location and provider. Open the Integrated Equipment Module From the IEM grid, select a Cardiac Science Resting ECG Report record with a Test Status of Confirmed, UnconfirmedOnly, or Reconfirmed. Select View Report. The HeartCentrix® Resting ECG report opens. Note: If the system finds a suitable match from information supplied in the Patient Information window, it populates the Race field. Otherwise, the field defaults to "Unknown." Select the HeartCentrix Main toolbar items as needed (functions are dependent on user permissions and view mode). After making any changes, select Confirm to save changes and return to the IEM. For more information on how to use HeartCentrix® functionalities, refer to the appropriate HeartCentrix® user manual. Parent topic: Hillrom HeartCentrix Devices

NextGen® Enterprise EHR Help

View Hillrom™ HeartCentrix® Holter Reports

After ordering a Hillrom™ HeartCentrix® (former Cardiac Science) Holter report, you can view it. Open the Integrated Equipment Module From the IEM grid, select a Cardiac Science Resting Holter Report record with a Test Status of Confirmed, UnconfirmedOnly, or Reconfirmed. Select View Report. The HeartCentrix® Holter report opens. Note: If the system finds a suitable match from information supplied in the Patient Information window, it populates the Race field. Otherwise, the field defaults to Unknown. Select the HeartCentrix Main toolbar items as needed (functions are dependent on user permissions and view mode). Enter your interpretation and select Confirm to save the changes. For more information on how to use HeartCentrix® functionalities, refer to the appropriate HeartCentrix® user manual. Parent topic: Hillrom HeartCentrix Devices

NextGen® Enterprise EHR Help

Delete Hillrom™ HeartCentrix® Reports

Hillrom™ HeartCentrix® (former Cardiac Science) reports are stored in the Cardiac Science database, while references to the reports are stored in NextGen® database. As a result, you must delete the report and associated references from both places. Open the Integrated Equipment Module From the IEM grid, select any Cardiac Science report and select View Report. A Cardiac Science report opens. In either Edit or Edit Demographics modes, select the Options menu on the Main toolbar and choose Delete Test. Note: Deleting a report prevents a user from accessing a test. The test is still stored in HeartCentrix® and can be reactivated with assistance from HeartCentrix® Technical Support. With the same report selected in the IEM grid, select the Red X(Delete) button on the top toolbar.A confirmation message appears. Select Yes to confirm the deletion. Note: For more information on deleting the report PDF, see the Deleting an Equipment Report PDF from an Encounter section. For more information on

NextGen® Enterprise EHR Help

Create GE Stress ECG Reports

Before you start recording, ensure that the equipment is connected to the PC. For more information on how to use GE CardioSoft, refer to the appropriate GE CardioSoft Operator's Manual. Prepare the patient for the test as needed. In NextGen® Enterprise EHR, load a patient and select a location and provider. Open the Integrated Equipment Module. Select Acquire Report and select GE CardioSoft Stress ECG. The GE CardioSoft application starts and displays the Test Information window. On the Test Information window: For each tab, enter or verify all relevant information and select OK. Before the test starts: Check the applied electrodes and verify the signal quality in all leads. If needed, configure and select appropriate settings and protocols. Select the F1: pretest button to start the Pretest phase. In the Pretest phase: Select the 12SL analysis button to acquire and analyze a baseline ECG. Select the F1: pretest button to advance to the next stage in the selected protocol. After the la

NextGen® Enterprise EHR Help

Create GE Resting ECG Reports

Before you start recording, ensure that the equipment is connected to the PC. For more information on how to use GE CardioSoft, refer to the GE CardioSoft Operator's Manual. Prepare the patient for the test as needed. In NextGen® Enterprise EHR, load a patient and select a location and provider. Access the IEM. Select Acquire Report and select GE CardioSoft Resting ECG. The GE CardioSoft application starts and displays the Test Information window. Before the test starts, configure and select the appropriate settings as needed. On the Test Information window: For each tab, enter or verify all relevant information. Then select OK. If you are performing a: 10-second ECG with analysis, select the ECG Acquisition button. Full disclosure ECG, select the Start Full Disclosure ECG button. Select the Stop FD/Post Test Review button to stop the test and display the Test Summary window. Use the tabs at the top of the page to view additional data. Perform any post-test related tasks by clicking th
