View Hillrom™ HeartCentrix® Holter Reports

NextGen® Enterprise EHR Help

View Hillrom™ HeartCentrix® Resting ECG Reports

After ordering a Cardiac Science Resting ECG report, you can view it. In NextGen® Enterprise EHR, load a patient and select a location and provider. Open the Integrated Equipment Module From the IEM grid, select a Cardiac Science Resting ECG Report record with a Test Status of Confirmed, UnconfirmedOnly, or Reconfirmed. Select View Report. The HeartCentrix® Resting ECG report opens. Note: If the system finds a suitable match from information supplied in the Patient Information window, it populates the Race field. Otherwise, the field defaults to "Unknown." Select the HeartCentrix Main toolbar items as needed (functions are dependent on user permissions and view mode). After making any changes, select Confirm to save changes and return to the IEM. For more information on how to use HeartCentrix® functionalities, refer to the appropriate HeartCentrix® user manual. Parent topic: Hillrom HeartCentrix Devices

NextGen® Enterprise EHR Help

View Hillrom™ HeartCentrix® Exercise ECG Reports

After ordering a Cardiac Science Exercise ECG report, you can view it. Open the Integrated Equipment Module From the IEM grid, select a Cardiac Science Exercise ECG Report record with a Test Status of Confirmed, UnconfirmedOnly, or Reconfirmed. Select View Report. The HeartCentrix® Exercise ECG report opens. Note: If the patient has multiple race entries, then for Cardiac Science multiple race entries, the race is interpreted as Other. If the system finds a suitable match from information supplied in the Patient Information window, it populates the Race field. Otherwise, the field defaults to "Unknown." Select the HeartCentrix Main toolbar items as needed (functions are dependent on user permissions and view mode). After making any changes, select Confirm to save changes and return to the IEM. For more information on how to use HeartCentrix® functionalities, refer to the appropriate HeartCentrix® user manual. Parent topic: Hillrom HeartCentrix Devices

NextGen® Enterprise EHR Help

Order Hillrom™ HeartCentrix® Reports

Typically, you order a test in NextGen® Enterprise EHR, perform the test at the acquisition device, and then go back to NextGen® Enterprise EHR to view the results. After a test is requested, the HeartCentrix® application automatically matches a test to a specific order. If you order a test that was previously performed, you need to match an existing test to the order you are creating. In NextGen® Enterprise EHR, load a patient and select a location and provider. Open the Integrated Equipment Module From the Acquire Report list, select a Cardiac Science device (ECG, Exercise ECG, or Holter) . The HeartCentrix Auto Search window opens. The system updates the screen every five seconds for tests coming in from acquisition devices. If tests are listed, highlight the pertinent test and select Select to match the order to the test. If no matches appear, select Tests Received to display the Manual Search tab and list all the tests received since the order was received. If tests are listed, hi

NextGen® Enterprise EHR Help

Delete Hillrom™ HeartCentrix® Reports

Hillrom™ HeartCentrix® (former Cardiac Science) reports are stored in the Cardiac Science database, while references to the reports are stored in NextGen® database. As a result, you must delete the report and associated references from both places. Open the Integrated Equipment Module From the IEM grid, select any Cardiac Science report and select View Report. A Cardiac Science report opens. In either Edit or Edit Demographics modes, select the Options menu on the Main toolbar and choose Delete Test. Note: Deleting a report prevents a user from accessing a test. The test is still stored in HeartCentrix® and can be reactivated with assistance from HeartCentrix® Technical Support. With the same report selected in the IEM grid, select the Red X(Delete) button on the top toolbar.A confirmation message appears. Select Yes to confirm the deletion. Note: For more information on deleting the report PDF, see the Deleting an Equipment Report PDF from an Encounter section. For more information on

NextGen® Enterprise EHR Help

Compare Midmark Stress ECG Reports

You can compare up to four Midmark ECGs from the same patient. For more information on how to use Midmark Stress ECG functionalities, refer to the appropriate Midmark operation manual. Open the Integrated Equipment Module Select the check boxes next to up to four Midmark Stress ECG reports in the IEM grid. Select Compare. The Stress Test Serial Comparison Report window opens. Select the following buttons to perform appropriate actions, as needed: Preview: Displays a print preview of the report. Print: Prints the report. Printer Setup: Enables you to change the printer settings. Help: Displays online help. Select Exit to close the report and return to the IEM. Parent topic: Midmark Stress ECGs

NextGen® Enterprise EHR Help

Create Midmark Holter Reports

To acquire Midmark Holter data, your workstation must have a security key installed and the ability to read a CompactFlash or SD card. For more information on how to use Midmark Holter functionalities, refer to the appropriate Midmark operation manual. Prepare the patient for the test as needed. Insert the CompactFlash or SD card with the recorded Holter data into the card reader. In NextGen® Enterprise EHR, load a patient and select a location and provider. Open the Integrated Equipment Module From the Acquire Report list, select Midmark Holter. The Holter Analysis window opens. On the Holter Analysis window: Enter the recording Start Time & Date. This time is in 24-hour format (for 1:00 pm., enter 13:00). Use the right arrow key to move from the hour digits to minute digits. To generate reports, check the Print Reports After Analysis box and then select Report Settings to choose which reports to print. Select the Flash Card option as the data source and select Browse. The Open File w
