View Metrics Flowsheets on the Care Guidelines Template

NextGen® Adaptive Content Engine Help Enterprise 8

Add a New Flowsheet Setup

Access the Flowsheets Setup practice template . Select a Condition by clicking the Condition field down-arrow and selecting a value from the list that opens . Click OK. Select a Provider by clicking the Provider field down-arrow and select a provider name from the Rendering Provider list (that is, list of providers currently in the system), if required. Click OK. Note: Selecting a provider creates a flowsheet setup at the provider level for the provider selected. Not selecting a provider creates a flowsheet setup at the practice level for all providers within the practice. In the Metric Flowsheet Items section, select details for a new metric to add to the flowsheet: Click the left field and select an appropriate category for the new flowsheet item from the list that opens. Click the right field and select the name of the new flowsheet item from the list that opens. Click Add to add the new metrics flowsheet item to the grid. Repeat steps 4 and 5 until you have finished adding items to

NextGen® Adaptive Content Engine Help Enterprise 8

Access Metrics on Care Guidelines

Click the Care Guidelines link on any template to access the Care Guidelines template. On the Care Guidelines template, click a disease or condition guideline listed in the blue left side bar under Outstanding Guidelines. If metrics are configured for the guideline, they appear on the Metrics panel in flowsheet format when the guideline is selected. Lab tests and Vital Signs categories have items relevant to the condition already configured to appear in the grid for tracking by default. Note: The Metrics panel appears blank until you select one of the patient's conditions. For more information about the Metrics panel and Care Guidelines, go to NextGen Healthcare Success Community and download the latest Care Guidelines User Guide for NextGen® Adaptive Content Engine . Parent topic: View Metrics Flowsheets on the Care Guidelines Template

NextGen® Adaptive Content Engine Help Enterprise 8

Setup Flowsheets for Metrics Panel in Care Guidelines

The Flowsheets Setup practice template is used to select metrics to track for patients in flowsheet format that appear in the Metrics panel on the Care Guidelines template. The Flowsheets Setup practice template can be used by all specialties. This document provides instructions for configuring metrics flowsheets on the Flowsheets Setup practice template. Flowsheet setups are included with NextGen Adaptive Content Engine (formerly NextGen KBM) the system, configured at the practice level. These flowsheet setups can be modified and new setups added. Flowsheets can also be setup by provider. See also: Add a New Flowsheet Setup Remove an Item from a Flowsheet Setup Rearrange the Order of Items in a Flowsheet Setup Open the Flowsheets Setup Practice Template You can create a flowsheet setup or configure the existing flowsheet. Add a New Flowsheet Setup Remove an Item from a Flowsheet Setup Rearrange the Order of Items in a Flowsheet Setup View Metrics Flowsheets on the Care Guidelines Temp

NextGen® Adaptive Content Engine Help Enterprise 8

Metrics

You can view the metrics for a patient and can be configured using the Flowsheets Setup template. In the Metrics panel you can view metrics for a patient, lab and vital signs values, for up to 10 rows of data. Data appears in a flowsheet format, you can be configure it on the Flowsheets Setup practice template. The Metrics data grid is view-only. Metrics When you first open the Care Guidelines grid view template and expand the Metrics panel, it appears blank. Flowsheets do not appear until you select a guideline listed in the left pane in Outstanding Guidelines. Note: A guideline should have metrics configured in order to display flowsheets. Flowsheets in the Metrics panel are configured on the Flowsheets Setup practice template. Default flowsheet is setup at the practice level and comes shipped with the system, and can be edited or added. You can also setup the flowsheets. Open the Flowsheets Setup Practice Template You can create a flowsheet setup or configure the existing flowsheet.

NextGen® Adaptive Content Engine Help Enterprise 8

View Metrics Flowsheet

Metrics flowsheet appear in the Metrics panel when you select a condition listed on the Care Guidelines template. To display conditions for care guidelines that are activated for the patient, do the following: Open NextGen® Enterprise EHR. Select the Care Guidelines link on any of the main template. The Care Guidelines Paged View template opens. In the Care Guidelines panel, select the Grid View link. The Care Guidelines grid view template opens. Select a condition listed in the left side pane in Outstanding guidelines. Metrics corresponding to the conditions selected appear in the panel in flowsheet format. Metrics Parent topic: Metrics

NextGen® Adaptive Content Engine Help Enterprise 8

Metrics

You can view the metrics for a patient and can configure on the Flowsheets Setup template. If metrics is configured for the guideline, they appear on the Metrics panel when the guideline is selected. By default, the categories Lab Test and Vital Signs are configured to display relevant items in the grid for tracking, based on the condition. View Metrics Flowsheet You can view the flowsheet for metrics that are activated for the patient using Metrics panel. Parent topic: Care Guidelines Grid View
