Matching Results Data

The system automatically matches the data based on panel name, collection date/time, and panel code. If the panel name and collection date/time or panel name and panel code in the Import section is completely matched with the result components of the EHR section then its a complete match if it does not match then it will look for a partial match.

The partial matching logic is based on the panel name or panel code, collection date/time matches with one of the panels in the patient’s chart, but the panel status and components values do not match. For partial matching, the action is replace or add. The action is replace if the panel is partially matched and the source is Consolidated Clinical Document Architecture (C-CDA). If the panel has been partially matched, but the source is not C-CDA then that panel is added from the Orders module. The action is add even if it is a partial match since the result components are different.

If the panel name and collection date/time or panel name and panel code in the Import section which is completely matched with the result components of the EHR section, then a link icon appears in the Match column in both EHR and Import sections and sets the Action in the Import section to Ignore and the EHR section to Keep. When you select the result in the Import section, then the matching result in the EHR section is highlighted.

Note: The Comments field is not considered for any matching results. Code can be Logical Observation Identifiers Names and Codes (LOINC), Systematized Nomenclature of Medicine (SNOMED), or a Current Procedural Terminology (CPT) code.

When the panel code or panel name and collection date/time are matching but the panel status or the number of result component or the result component description or result values or observation dates or reference ranges or abnormal flags values or units are different and the source is not C-CDA in the EHR section then the default action is Add in the Import section, and matching results are highlighted with the link icon in the Match column in both EHR and Import sections.

When the panel code or panel name and collection date/time are matching but the result values or the number of result component or the result component description or observation dates or reference ranges or abnormal flags values or units are different and the source is C-CDA in the EHR section then the default action is Replace in the Import section, and matching results are highlighted with the link icon in the Match column in both EHR and Import sections.

If you hover over the matching icon then the description appears in the Import section.
