OCSP Revocation Checking

SSL Manager User Guide

CRL Revocation Checking

If enabled, Certificate Revocation List (CRL) checking will be done on all local and remote certificates. The issuer of the CRL must be included in your trusted certificates as well in order to verify signatures. CRL Enabled option on the SSL Settings window Select the wrench icon to open the CRL Settings window: CRL Settings window with CRL URI field and Hard Fail option CRL URI: This setting is optional. If specified, this URI will be used in addition to any certificate CRL Distribution Points when checking for revocation. HTTP, File FTP, or LDAP URIs are supported. Hard Fail: When enabled, this connector will depend on the remote CRL provider. If a CRL cannot be downloaded or verified for any reason, all connections will fail revocation checks. Parent topic: Common Connector SSL Settings

SSL Manager User Guide

Subject DN Validation

If enabled, only client certificates with subject distinguished names (DNs) matching the given list will be allowed. If a client certificate not matching any of the trusted DNs is presented, the SSL connection / handshake will fail. Subject DN Validation option on the SSL Settings window Select the wrench icon to open the Trusted Subject DNs window: Set Trusted Certificate Subject DNs window Select the New / Delete buttons to add or remove entries. For each Trusted Subject DN entry, configure the following: Distinguished Name: The full or partial distinguished name (DN) to trust. This will be matched against the Subject DN of the remote certificate. Full Match: If enabled, all components (RDNs) configured here must match the ones in the certificate, and the subject DN cannot have any additional components. If disabled, the components configured here will only be considered a required subset, and the subject DN may have additional components. Example 1 Example 2 Example 3 Parent topic:

SSL Manager User Guide

Additional Allowed Hosts

Additional Allowed Hosts is an optional feature that lets you specify extra host names to be verified alongside the primary host name set in the Remote Address field. Buttons on the Additional Allowed Hosts window that allow you to maintain the list of host names. Item Name Description A New Enter additional host names. B Delete Delete one or more additional host names. When establishing a secure connection, Mirth® Connect performs host name verification to ensure that the host name you are connecting to matches the names listed in the remote server’s SSL/TLS certificate (typically found in the Subject CN or SAN fields). However, if you are using Velocity variables (such as variables from the Connector Map or Channel Map) in the Remote Address field, host name verification may fail. The Additional Allowed Hosts window provides a solution by allowing you to define a list of explicit host names that Mirth® Connect can use for verification if the primary one fails. It is recommended to us

SSL Manager User Guide

Common Connector SSL Settings

The following sections provide descriptions and examples of common connector SSL settings. Additional Allowed Hosts Subject DN Validation OCSP Revocation Checking CRL Revocation Checking Enabled TLS/SSL Protocols Enabled TLS/SSL Cipher Suites Additional Allowed Hosts Additional Allowed Hosts is an optional feature that lets you specify extra host names to be verified alongside the primary host name set in the Remote Address field. Subject DN Validation OCSP Revocation Checking CRL Revocation Checking Enabled TLS/SSL Protocols Enabled TLS/SSL Cipher Suites

Mirth® Connect by NextGen Healthcare User Guide

SSL Manager Extension

This section only applies if you have the SSL Manager extension installed. This guide will summarize the available settings, but there is a separate user guide specifically written for the SSL Manager that goes into depth about all the available features. Contact our help desk to obtain a copy of the SSL Manager guide. Source Connector Settings Client Authentication: Client authentication (sometimes called mutual or bi-lateral authentication) can provide additional security as both the client and server must present certificates that the other can choose to trust or not. The Trusted Client Certificatessection determines which client certs (or intermediate/root certs) to trust. Present Issuer DNs: This is only applicable when Client Authentication is used. If enabled, during the SSL handshake the server will respond with a list of accepted client issuer distinguished names (DNs). Disabling this can provide extra security as potential attackers are given less information about the correc

SSL Manager User Guide

Apply Source Connector SSL Settings

On the Channels page, double-click a channel in the Channel list. Select the Source tab. In the Connector Type field, select the connector type that supports the SSL Manager (for example, HTTP Listener, Web Service Listener, File Reader in FTP mode). In the SSL Settings section - Enable field, select Yes. Enabling SSL Settings Select the wrench icon to open the SSL Settings window: Items on the SSL Settings Window Item Name Default Value Description A My Server Certificate None Select the local certificate used to identify this listener connector. For additional information, see My Server Certificate B Client Authentication Disabled Disabled: No client authentication is requested. Request: Client certificate is requested but not required. If the client presents a certificate it will be used for extra security. Require: Client certificate is required. If the client does not present a certificate, the handshake will fail. C Client Certificate Validation Enabled If enabled, only the certi
