Code Template Contexts

Mirth® Connect by NextGen Healthcare User Guide

Library Resources

Resources are shared services that can be used in specific channels / connectors or in other places throughout the Mirth® Connect server. They may include custom Java libraries to use within scripts, or services to handle outbound connections. The Library Resources tab allows you to include resources throughout your entire channel, or in more specific contexts such as the channel scripts or certain connectors. The Library Context tree in the top section of the tab allows you to select a specific context, or the Channel root-level node which represents all contexts across your channel at once. The following library contexts are available: Library Context Description Channel This is the root-level node of the tree, and includes all contexts below it. If one of the resource check boxes in the table below is in the indeterminate state (grey box), it means that it is currently included on some but not all of the sub-contexts. Channel Scripts This includes the deploy, undeploy, preprocessor,

Mirth® Connect by NextGen Healthcare User Guide

Connector-Specific Properties

Every connector has its own custom set of properties. The properties you configure for a TCP Listener will be different from a Database Writer and so on. Here is a list of source and destination connectors supported by Mirth® Connect: Source Connectors Channel Reader DICOM Listener Database Reader File Reader HTTP Listener JMS Listener JavaScript Reader TCP Listener Web Service Listener Destination Connectors Channel Writer DICOM Sender Database Writer Document Writer File Writer HTTP Sender JMS Sender JavaScript Writer SMTP Sender TCP Sender Web Service Sender Additional connectors are made available as extensions: Email Reader Serial Connector NextGen Results CDR Connector FHIR Connector Interoperability Connector Suite Parent topic: Connector Components

Mirth® Connect by NextGen Healthcare User Guide

Code Template Tasks

The following context-specific tasks are available throughout the Edit Code Templates View: Task Icon Task Name Description Refresh Refreshes the list of code templates / libraries. If there are unsaved changes, you are prompted to save first before refreshing. Save Changes Saves all changes made to all code templates / libraries. Changes to a code template will cause its revision to increment. Changes to a library, or adding/removing code templates to/from the library, will cause its revision to increment. New Code Template Creates a new code template in the currently selected library. If there are currently no libraries configured for your server, you must first create a new library before this task becomes available. New Library Creates a new code template library and adds it to the table. By default the library is not included in any channels. Use the Channels table in the Edit Library Panel to link the library to specific channels. Import Code Templates Import a single code templa

Mirth® Connect by NextGen Healthcare User Guide

Code Template Libraries

This tab allows you to link code template libraries to the current channel you are editing. Note that this accomplishes the same thing as including channels on the Edit Library Panel within the Edit Code Templates View. It is included here as well within the Edit Channel View for convenience. The tree within this tab is organized in a way that Libraries are the top-level nodes, and each Code Template underneath is a child of that library. Select any library or code template row, and if a description is available, it will show in the bottom section of the dialog. Link Code Template Libraries Parent topic: Set Dependencies Window

Mirth® Connect by NextGen Healthcare User Guide

Edit Data Types

You can edit the properties for the destination transformer's inbound data type. A filter only has access to the inbound data type, while a transformer has access to both inbound and outbound data types. Additionally, when editing the destination transformer the inbound data type may not be changed, since it must remain the same as the source connector's outbound data type. However, you can still edit the properties for the destination transformer's inbound data type. An image of the Message Templates tab editing the inbound data type. When selecting the Properties button, a dialog opens allowing you to edit the various inbound or outbound properties for the data type. This is a subset of the view shown in the Set Data Types Window. For additional information, see About Data Types and Data Types. Parent topic: Message Templates Tab

Mirth® Connect by NextGen Healthcare User Guide

Edit Channel Tasks

The following context-specific tasks are available throughout the Edit Channel View: Task Icon Task Name Description Save Changes Saves a new revision of the current channel, if anything was actually changed. Validate Connector Validates the currently viewed connector, ensuring that all connector properties are valid and able to be saved. Edit Filter Enters the Edit Filter View for the currently viewed connector. Edit Transformer Enters the Edit Transformer View for the currently viewed connector. Import Connector Imports a connector from an XML file into the current channel. For source connectors, this completely overrides all source connector properties and the source filter/transformer. For destination connectors a new destination is added to the table. Export Connector Exports the currently viewed connector to an XML file. This includes all connector properties and the connector's filter / transformer. Export Channel Exports the current channel to an XML file. The channel must be s
